8.1.4 BPG 300
Parameter Unit BPG 300
Tube height mm 500 750 950
Column inner diameter mm 296
Cross sectional area cm
2
688
Max column volume l 27 44 58
Max column volume with extension l 53 70 84
Min bed height cm 3 28 48
Bed height
1
cm 25 41 54
Bed height with extension
2
cm 33 55 72
Bed height with extension
3
cm 45 66 N/A
Min bed volume l 0.6 19.2 33.0
Bed volume
1
l 17.2 28.2 37.1
Bed volume with extension
2
l 22.7 37.8 49.5
Bed volume with extension
3
l 30.9 45.4 N/A
Max pressure
4
bar(g) 4
Total weight (tare mass) kg 68 73 78
Total weight (tare mass) with extension kg 89 94 99
Adapter weight kg 29
Overall dimension D×W×H cm 69×69×133 69×69×158 69×69×178
Height with extension tube cm 171 196 216
Operating temperature °C 4 to 40
1
W
ithout an extension tube.
2
These bed heights and volumes are achievable using a packing extension during consolidation of the bed (sedimen-
tation). Total amount of 75% slurry must fit into column + extension with adapter.
3
The bed height and volume are achievable when retaining the extension tube during the final packing step. Adapter
must seal at least 5 cm into the column tube to avoid high tensions on glass tube.
4
Use a pressure gauge to monitor the pressure.
8 Reference information
8
.1 Specifications
8.1.4 BPG 300
130
BPG Columns Operating Instructions 29193223 AB
