8.1.2 BPG 140
Parameter Unit BPG 140
Tube height mm 500 750 950
Column inner diameter mm 140
Cross sectional area cm
2
154
Max column volume l 6.3 10 13
Max column volume with extension l 12 16 19
Min bed height cm 1 26 46
Bed height
1
cm 26 42 55
Bed height with extension
2
cm 35 55 74
Bed height with extension
3
cm 45 67 N/A
Min bed volume l 0.1 4.0 7.0
Bed volume
1
l 4.0 6.4 8.4
Bed volume with extension
2
l 5.3 8.4 11.3
Bed volume with extension
3
l 6.9 10.3 N/A
Max pressure
4
bar(g) 6
Total weight (tare mass) kg 25 26 27
Total weight (tare mass) with extension kg 34 35 36
Adapter weight kg 11
Overall dimension D×W×H cm 59×59×127 59×59×152 59×59×172
Height with extension tube cm 165 190 210
Operating temperature °C 4 to 40
1
W
ithout an extension tube.
2
These bed heights and volumes are achievable using a packing extension during consolidation of the bed (sedimen-
tation). Total amount of 75% slurry must fit into column + extension with adapter.
3
The bed height and volume are achievable when retaining the extension tube during the final packing step. Adapter
must seal at least 5 cm into the column tube to avoid high tensions on glass tube.
4
Use a pressure gauge to monitor the pressure.
8 Reference information
8
.1 Specifications
8.1.2 BPG 140
128
BPG Columns Operating Instructions 29193223 AB
