8.1.3 BPG 200
Parameter Unit BPG 200
Tube height mm 500 750 950
Column inner diameter mm 200
Cross sectional area cm
2
314
Max column volume l 13 21 27
Max column volume with extension l 25 33 39
Min bed height cm 1 26 46
Bed height
1
cm 26 42 55
Bed height with extension
2
cm 35 56 74
Bed height with extension
3
cm 45 67 N/A
Min bed volume l 0.3 8.1 14.4
Bed volume
1
l 8.1 13.1 17.2
Bed volume with extension
2
l 10.9 17.5 23.2
Bed volume with extension
3
l 14.1 21.0 N/A
Max pressure
4
bar(g) 6
Total weight (tare mass) kg 34 36 39
Total weight (tare mass) with extension kg 45 47 50
Adapter weight kg 13
Overall dimension D×W×H cm 59×59×127 59×59×152 59×59×172
Height with extension tube cm 165 190 210
Operating temperature °C 4 to 40
1
W
ithout an extension tube.
2
These bed heights and volumes are achievable using a packing extension during consolidation of the bed (sedimen-
tation). Total amount of 75% slurry must fit into column + extension with adapter.
3
The bed height and volume are achievable when retaining the extension tube during the final packing step. Adapter
must seal at least 5 cm into the column tube to avoid high tensions on glass tube.
4
Use a pressure gauge to monitor the pressure.
8 Reference information
8
.1 Specifications
8.1.3 BPG 200
BPG Columns Operating Instructions 29193223 AB 129
