8.1.5 BPG 450
Parameter Unit BPG 450
Tube height mm 500 750 1000
Column inner diameter mm 446
Cross sectional area cm
2
1562
Max column volume l 56 95 134
Max column volume with extension l 103 142 181
Min bed height cm 16 28 53
Bed height
1
cm 23 39 55
Bed height with extension
2
cm 30 52 74
Bed height with extension
3
cm 42 59 N/A
Min bed volume l 25.0 43.7 82.8
Bed volume
1
l 35.9 60.9 85.9
Bed volume with extension
2
l 46.8 81.2 115.6
Bed volume with extension
3
l 65.6 92.1 N/A
Max pressure
4
bar(g) 2.5
Total weight (tare mass) kg 200 215 230
Total weight (tare mass) with extension kg 225 240 255
Adapter weight kg 100
Overall dimension D×W×H cm 80×80×140 80×80×165 80×80×190
Height with extension tube cm 170 195 220
Operating temperature °C 4 to 40
1
W
ithout an extension tube.
2
These bed heights and volumes are achievable using a packing extension during consolidation of the bed (sedimen-
tation). Total amount of 75% slurry must fit into column + extension with adapter.
3
The bed height and volume are achievable when retaining the extension tube during the final packing step. Adapter
must seal at least 5 cm into the column tube to avoid high tensions on glass tube.
4
Use a pressure gauge to monitor the pressure.
8 Reference information
8
.1 Specifications
8.1.5 BPG 450
BPG Columns Operating Instructions 29193223 AB 131
