xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
88
System Severity Alerts
Figure 6- 57. System Severity Settings
Use the drop-down menus to configure the parameters described below.
Parameter Description
Severity Name
Choose how the alerts are used from the drop-down menu. Select log to send the alert of the
Severity Type configured to the Switch’s log for analysis. Choose trap to send it to an SNMP
agent for analysis, or select all to send the chosen alert type to an SNMP agent and the
Switch’s log for analysis.
Severity Type
Choose what level of alert will trigger sending the log entry or trap message as defined by the
Severity Name. Select critical to send only critical events to the Switch’s log or SNMP agent.
Choose warning to send critical and warning events to the Switch’s log or SNMP agent. Select
information send informational, warning and critical events to the Switch’s log or SNMP agent.
Click Apply to implement the new System Severity alert level.
System Log Server
Figure 6- 58. System Log Servers window
The parameters configured for adding and editing System Log Server settings are the same. See the table below for a description.
The Switch can be configured to allow alerts be
logged or sent as a trap to an SNMP agent or
both. The level at which the alert triggers either
a log entry or a trap message can be set as well.
Use the System Severity Settings menu to set the
criteria for alerts. The current settings are
displayed below the Settings menu. To view this
window click, Configuration > System
Severity Alerts.
NOTE: For detailed
information regarding Log
entries that will appear in
this window, please refer to
Appendix C at the back of
this manual.
The Switch can send Syslog messages to as many
as four designated servers using the System Log
Server. To view this window click,
Configuration > System Log Server.
