xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
222
IGMP Snooping Forwarding
This window will display the current IGMP snooping forwarding table entries currently configured on the Switch. To view the
following screen, click, Monitoring > IGMP Snooping Forwarding.
Figure 8- 19. IGMP Snooping Forwarding Table window
The user may search the IGMP Snooping Forwarding Table by VID clicking the top left hand corner Search button.
The following field can be viewed:
Parameter Description
VLAN ID
The VLAN ID (VID) of the multicast group.
Multicast Group
The IP address of the multicast group.
MAC Address
The MAC address of the multicast group.
Port Map
These are the ports where the IGMP packets were snooped are displayed.
