xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
131
Limited IP Multicast Range Status Setting
After Multicast Range Profiles are created, you may start to configure the multicast address filtering function on a port or a range
of ports by configuring the Limited IP Multicast Range Status window as below. To view the following window, click
Configuration > Limited IP Multicast Range > Limited IP Multicast Range Status Settings window.
Figure 6- 111 Limited Multicast Range Status Settings window
Parameter Description
From…To
Select a port or group of ports using the pull-down menus.
State
Toggle the State field to either Enabled or Disabled a given port or group of ports where
access is to be either permitted or denied.
Access
Two options are available: Permint and Deny. The default mode is Permit.
Permint specifies that the packet that match the addresses defined in the profiles will be
permitted. Deny specifies that the packet that match the addresses defined in the profiles will
be denied.
