xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
24
Various areas of the graphic can be selected for performing management functions, including port
configuration.
Area 3
Presents switch information based on your selection and the entry of configuration data.
NOTICE: Any changes made to the Switch configuration during the current session must be saved
in the Save Changes web menu (explained below) or use the command line interface (CLI)
command save.
Web Pages
When you connect to the management mode of the Switch with a web browser, a login window is displayed. Enter a user name
and password to access the Switch's management mode.
Below is a list and description of the main folders available in the web interface:
Configuration – Contains windows concerning configurations for Switch Information, IP Address, Advanced Settings, Port
Configuration, Port Description, Port Mirroring, Link Aggregation, LACP Port Setting, MAC Notification, IGMP, Spanning Tree,
Loopback Detection, Forwarding Filtering, VLANs, Traffic Control, Port Security, QoS, System Severity Settings, System Log
Server, SNTP Settings, ACL, Time Range Settings, IP-MAC Binding, Limited IP Multicast Range and Layer 3 IP Networking
and LLDP.
Security Management – Contains windows concerning configurations for Security including Trusted Host, User Accounts, Port
Access Entity, Access Authentication Control, Secure Sockets Layer (SSL), Secure Shell (SSH), SNMP Manager, Safeguard
Engine Settings, Filter and ARP Spoofing Prevention.
Monitoring – Contains windows concerning monitoring the Switch, pertaining to Port Utilization, CPU Utilization, Memory
Usage, Packets, Errors, Size, MAC Address, Switch History Log, IGMP Snooping Group, IGMP Snooping Forwarding, VLAN
Status, Router Port, Port Access Control, Layer 3 Feature, Safeguard Engine Status and Cable Diagnostics.
Maintenance – Contains windows concerning configurations and information about Switch maintenance, including TFTP
Services, Multiple Image Services, Ping Test, Save Changes, Reset, Reset System, Reset Config, Reboot Device and Logout.
Single IP Management – Contains windows concerning information on Single IP Management, including SIM Settings,
Topology, and Firmware/Configuration downloads.
NOTE: Be sure to configure the user name and password in the User Accounts menu
before connecting the Switch to the greater network.
NOTICE: In case of lost passwords or password corruption, please refer to the
D-Link website and the White Paper entitled “Password Recovery Procedure”,
which will guide you through the steps necessary to resolve this issue.
