xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
188
SNMP User Table
The SNMP User Table displays all of the SNMP User's currently configured on the Switch.
To view this window click, Security Management > SNMP Manager > SNMP User Table.
Figure 7- 44. SNMP User Table window
To delete an existing SNMP User Table entry, click the
button under the Delete heading corresponding to the entry you wish
to delete.
To display the detailed entry for a given user, click on the hyperlinked User Name. This will open the SNMP User Table Display
window, as shown below.
Figure 7- 45. SNMP User Table Display window
The following parameters are displayed:
Parameter Description
User Name
An alphanumeric string of up to 32 characters. This is used to identify the SNMP users.
Group Name
This name is used to specify the SNMP group created can request SNMP messages.
SNMP Version
V1 - Indicates that SNMP version 1 is in use.
V2 - Indicates that SNMP version 2 is in use.
V3 - Indicates that SNMP version 3 is in use.
Auth-Protocol
None - Indicates that no authorization protocol is in use.
MD5 - Indicates that the HMAC-MD5-96 authentication level will be used.
SHA - Indicates that the HMAC-SHA authentication protocol will be used.
Priv-Protocol
None - Indicates that no authorization protocol is in use.
DES - Indicates that DES 56-bit encryption is in use based on the CBC-DES (DES-56)
standard.
To return to the SNMP User Table, click the Show All SNMP User Table Entries link.
To add a new entry to the SNMP User Table Configuration window, click on the Add button on the SNMP User Table window.
This will open the SNMP User Table Configuration window, as shown below.
