xStack
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
48
Source Port
A port on the Switch to be designated as the source port for multicast traffic. Multicast traffic
entering the switch will be forwarded from this port to member ports on the same VLAN.
Note that the Source port must be different from the member ports of the created VLAN.
Member Port
A port or range of member ports to add to the multicast VLAN. These ports will receive
multicast traffic from the source port. Remember, the source port cannot be the same as any
member port.
Click Apply to configure the multicast VLAN.
Note: Once a Multicast VLAN has been configured and enabled on the switch, other IGMP Snooping
settings will be overridden and the IGMP Snooping Multicast VLAN will take precedence.
