xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
104
Figure 4-68 IPv4 Multicast Profile Settings window
The fields that can be configured are described below:
Parameter Description
Enter a Profile ID between 1 and 24.
Enter a name for the IP Multicast Profile.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
Click the Group List
link to configure the multicast address group list settings for the specific entry.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
After clicking the Group List
link, the following page will appear:
Figure 4-69 Multicast Address Group List Settings window
The fields that can be configured are described below:
Parameter Description
Display the profile name.
Enter the multicast address list here.
Click the Add button to add a new entry based on the information entered.
Click the <<Back button to discard the changes made and return to the previous page.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
IPv6 Limited Multicast Range Settings
Users can configure the ports and VLANs on the Switch that will be involved in the Limited IPv6 Multicast Range.
To view the following window, click L2 Features > Multicast Filtering > IPv6 Multicast Filtering > IPv6 Limited
Multicast Range Settings, as show below:
