D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
245
Figure 10-8 CFM Port Settings Window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Use the drop-down menus to select a range of ports to be configuration.
State
Use the drop-down menu to enable or disable the state of specific port regarding the
CFM configuration.
Click the Apply button to accept the changes made.
CFM MIPCCM Table
This window is used to show the MIP CCM database entries.
To view this window, click OAM > CFM > CFM MIPCCM Table, as shown below:
Figure 10-9 CFM MIPCCM Table Window
CFM Loopback Settings
This window is used to start a CFM loopback test.
To view this window, click OAM > CFM > CFM Loopback Settings, as shown below:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
