D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
185
Figure 8-23 RADIUS Accounting Settings window
The fields that can be configured are described below:
Parameter Description
Network
When enabled, the Switch will send informational packets to a remote RADIUS server
when 802.1X port access control events occur on the Switch.
Shell
When enabled, the Switch will send informational packets to a remote RADIUS server
when a user either logs in, logs out or times out on the Switch, using the console, Telnet,
or SSH.
System
When enabled, the Switch will send informational packets to a remote RADIUS server
when system events occur on the Switch, such as a system reset or system boot.
Click the Apply button to accept the changes made.
RADIUS Authentication
Users can display information concerning the activity of the RADIUS authentication client on the client side of the
RADIUS authentication protocol.
To view this window, click Security > RADIUS > RADIUS Authentication as shown below:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
