xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
231
NOTE: When there is no matching server found for the packet based on option 60, the relay servers
will be determined by the default relay server setting.
DHCP Relay Option 60 Settings
This option decides whether the DHCP Relay will process the DHCP option 60 or not
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 60 Settings as
shown below:
Figure 9-6 DHCP Relay Option 60 Settings window
The fields that can be configured are described below:
Parameter Description
String
Enter the DHCP Relay Option 60 String value. Different strings can be specified for the
same relay server, and the same string can be specified with multiple relay servers.
The system will relay the packet to all the matching servers.
Here the user can enter the DHCP Relay Option 60 Server IP address.
Match Type
Here the user can enter the DHCP Relay Option 60 Match Type value.
Exact Match – The option 60 string in the packet must full match with the specified
string.
Partial Match – The option 60 string in the packet only need partial match with the
Enter the DHCP Relay Option 60 IP address.
Enter the DHCP Relay Option 60 String value.
Click the Add button to add a new entry based on the information entered.
Click the Find button to locate a specific entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Show All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Delete button to remove the corresponding entry.
DHCP Relay Option 61 Settings
This window is used to configure, add and delete DHCP relay option 61 parameters.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 61 Settings as
shown below:
