xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
15
Figure 2-10 Warning Temperature Settings window
The fields that can be configured are described below:
Parameter Description
Traps State
Use the drop-down menu to enable or disable the traps state option of the warning
Log State
Use the drop-down menu to enable or disable the log state option of the warning
High Threshold
Enter the high threshold value of the warning temperature setting.
Low Threshold
Enter the low threshold value of the warning temperature setting.
Click the Apply button to implement changes made.
System Log Configuration
System Log Settings
The Switch allows users to choose a method for which to save the switch log to the flash memory of the Switch.
To view the following window, click System Configuration > System Log Configuration > System Log Settings,
as show below:
Figure 2-11 System Log Settings window
The fields that can be configured are described below:
Parameter Description
Use the radio buttons to enable or disable the system log settings.
Save Mode
Use the drop-down menu to choose the method for saving the switch log to the flash memory.
The user has three options:
On Demand – Users who choose this method will only save log files when they manually tell
the Switch to do so, either using the Save Log link in the Save folder.
Time Interval – Users who choose this method can configure a time interval by which the
Switch will save the log files, in the box adjacent to this configuration field. The user may set
a time between 1 and 65535 minutes.
Log Trigger – Users who choose this method will have log files saved to the Switch every
time a log event occurs on the Switch.
