D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
196
Figure 8-34 MAC-based Access Control Local Settings – Edit by Name window
To change the selected MAC address’ VID value, the user can click the Edit by ID button.
Figure 8-35 MAC-based Access Control Local Settings – Edit by ID window
Click the Apply button to accept the changes made.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MAC-based Access Control Authentication State
This window is used to display MAC-based access control authentication state information.
To view this window, click Security > MAC-based Access Control (MAC) > MAC-based Access Control
Authentication State as shown below:
Figure 8-36 MAC-based Access Control Authentication State window
The fields that can be configured are described below:
Parameter Description
Port List
Enter a list of ports to be displayed.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear by Port button to clear all the information linked to the port number entered.
Click the View All Hosts button to display all the existing hosts.
Click the Clear All Hosts button to clear out all the existing hosts.
Compound Authentication
Compound Authentication settings allows for multiple authentication to be supported on the Switch.
