xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
60
Click the Delete All button to remove all the entries listed.
Click the Edit button to re-configure the specific entry.
Click the Delete button to remove the specific entry.
GVRP
GVRP Global Settings
Users can determine whether the Switch will share its VLAN configuration information with other GARP VLAN
Registration Protocol (GVRP) enabled switches. In addition, Ingress Checking can be used to limit traffic by filtering
incoming packets whose PVID does not match the PVID of the port. Results can be seen in the table under the
configuration settings.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Global Settings, as show below:
Figure 4-10 GVRP Global Settings window
The fields that can be configured are described below:
Parameter Description
Click the radio buttons to enable or disable the GVRP State.
Enter the Join Time value in milliseconds.
Enter the Leave Time value in milliseconds.
Leave All Time (100-
Enter the Leave All Time value in milliseconds.
NNI BPDU Address
Used to determine the GVRP PDU protocol address for GVRP in service provide
site. It can use 802.1D GVRP address or 802.1ad service provider GVRP
Click the Apply button to accept the changes made for each individual section.
NOTE: The Leave Time value should be greater than twice the Join Time value. The Leave All Time
value should be greater than the Leave Time value.
GVRP Port Settings
On this page the user can configure the GVRP port parameters.
To view the following window, click L2 Features > VLAN > GVRP > GVRP Port Settings, as show below:
