xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
191
IMPB Entry Settings
This window is used to create static IP-MAC-binding port entries and view all IMPB entries on the Switch.
To view this window, click Security > IP-MAC-Port Binding (IMPB) > IMPB Entry Settings as shown below:
Figure 8-28 IMPB Entry Settings window
The fields that can be configured are described below:
Parameter Description
Enter the IP address to bind to the MAC address set below.
Enter the MAC address to bind to the IP Address set above.
Ports
Specify the switch ports for which to configure this IP-MAC binding entry (IP Address
+ MAC Address). Tick the All Ports check box to configure this entry for all ports on
Click the Apply button to accept the changes made.
Click the Find button to locate a specific entry based on the information entered.
Click the View All button to display all the existing entries.
Click the Delete All button to remove all the entries listed.
Click the Edit button to configure the specified entry.
Click the Delete button to remove the specified entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
MAC Block List
This window is used to view unauthorized devices that have been blocked by IP-MAC binding restrictions.
To view this window, click Security > IP-MAC-Port Binding (IMPB) > MAC Block List as shown below:
Figure 8-29 MAC Block List
The fields that can be configured are described below:
Parameter Description
