D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
180
Authenticator Statistics
This window is used to display the authenticator statistics information.
To view this window, click Security > 802.1X > Authenticator Statistics as shown below:
Figure 8-15 Authenticator Statistics window
The fields that can be configured are described below:
Parameter Description
Time Interval
Use the drop-down menu to select the interval to update the statistics.
Click the OK button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings
window before initializing ports. Information in this window cannot be viewed before enabling
the authentication mode for either Port-based or MAC-based.
Authenticator Session Statistics
This window is used to display the authenticator session statistics information.
To view this window, click Security > 802.1X > Authenticator Session Statistics as shown below:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
