D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
184
RADIUS
Authentication RADIUS Server Settings
The RADIUS feature of the Switch allows the user to facilitate centralized user administration as well as providing
protection against a sniffing, active hacker.
To view this window, click Security > RADIUS > Authentication RADIUS Server Settings as shown below:
Figure 8-22 Authentication RADIUS Server Settings window
The fields that can be configured are described below:
Parameter Description
Index
Choose the desired RADIUS server to configure: 1, 2 or 3.
Server IP
Set the RADIUS server IP address.
Authentication Port (1-
65535)
Set the RADIUS authentic server(s) UDP port which is used to transmit
RADIUS data between the Switch and the RADIUS server. The default port is
1812.
Accounting Port (1-65535)
Set the RADIUS account server(s) UDP port which is used to transmit RADIUS
accounting statistics between the Switch and the RADIUS server. The default
port is 1813.
Timeout (1-255)
Set the RADIUS server age-out, in seconds.
Retransmit (1-20)
Set the RADIUS server retransmit time, in times.
Key
Set the key the same as that of the RADIUS server.
Confirm Key
Confirm the key the same as that of the RADIUS server.
Click the Apply button to accept the changes made.
RADIUS Accounting Settings
Users can configure the state of the specified RADIUS accounting service.
To view this window, click Security > RADIUS > RADIUS Accounting Settings as shown below:

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
