D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
182
Figure 8-17 Authenticator Diagnostics window
The fields that can be configured are described below:
Parameter Description
Time Interval
Use the drop-down menu to select the interval to update the statistics.
Click the OK button to accept the changes made.
NOTE: The user must first globally enable Authentication Mode in the 802.1X Global Settings
window before initializing ports. Information in this window cannot be viewed before enabling
the authentication mode for either Port-based or MAC-based.
Initialize Port(s)
This window is used to initialize the port description.
To view this window, click Security > 802.1X > Initialize Port(s) as shown below:
If Port-based is selected in the Authentication Mode drop-down menu in 802.1X Global Settings window, the
following window appears.
Figure 8-18 Initialize Port(s) - Port-based window
If MAC-based is selected in the Authentication Mode drop-down menu in 802.1X Global Settings window, the
following window appears.

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
