D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
277
The fields that can be configured are described below:
Parameter Description
FTP Server IP
Enter the FTP Server IP Address used.
User Name
Enter the appropriate Username used.
Password
Enter the appropriate Password used.
TCP Port (1-65535)
Enter the TCP Port number used.
Destination File
Enter the file name that will be stored in the FTP server, e.g. config.cfg.
Source File
Enter the location of the Source File, e.g. C:/config.cfg.
Filter
Use the drop-down menu to include, begin or exclude a filter like SNMP, VLAN or STP.
Select the appropriate Filter action and enter the service name in the space provided.
Click Upload to initiate the upload.
Upload Configuration To HTTP
This window is used to upload the configuration file from the Switch to a computer.
Figure 12-14 Upload Configuration – HTTP window
The fields that can be configured are described below:
Parameter Description
Source File
Enter the location and name of the Source File.
Click Upload to initiate the upload.
Upload Log File
The following window is used to upload the log file from the Switch.
Upload Log To TFTP
This window is used to upload the log file from the Switch to a TFTP Server.
Figure 12-15 Upload Log – TFTP window

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
