D-Link xStack DES-3200 Series Reference Guide

xStack® DES-3200 Series Layer 2 Managed Fast Ethernet Switch
255
The fields that can be configured are described below:
Parameter Description
Port
Select a port you wish to display.
Click the Test button to view the cable diagnostics for a particular port.
NOTE: Cable diagnostic function limitations. Cable length detection is only supported on GE ports if
the port or the link partner is powered off. Ports must be linked up and running at 1000M
speed. Cross-talk errors detection is not supported on FE ports.
Test Result messages:
• Open - The cable in the error pair does not have a connection at the specified position.
• Short - The cable in the error pair has a short problem at the specified position.
• Crosstalk - The cable in the error pair has a crosstalk problem at the specified position.
• Shutdown - The remote partner is powered off.
• Unknown - The diagnosis does not obtain the cable status. Please try again.
• OK - The pair or cable has no error.
• No cable - The port does not have any cable connected to the remote partner.
