D-Link xStack DES-3200 Series User Manual

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
13
5
config 802.1p default_priority
Used to co
nfigure the 802.1p default priority settings on the Switch. If an untagged packet is
received by the Switch, the priority configured with this command will be written to the
packet’s priority field.
Purpose
config 8
02.1p default_priority [<portlist> | all] <priority 0-7>
Syntax
This
command is used to specify default priority handling of untagged packets received by
the Switch. The priority value entered with this command will be used to determine to which
of the four hardware priority queues the packet is forwarded.
Description
Parameters
<portlist>  Specifies a port or range of ports to be configured.
all  Specifies that the command applies to all ports on the Switch.
<priority 0-7>  The priority value to assign to untagged packets received by the Switch or a
range of ports on the Switch.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure 802.1p default priority on the Switch:
DES-3200-28:4#config 802.1p default_priority all 5
Command: config 802.1p default_priority all 5
Success.
DES-3200-28:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
