xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
13
7
config cos mapping
Used to co
nfigure the CoS to port mapping method to be used on
the switch.
Purpose
config
cos mapping ports [<portlist> | all] [none | { ethernet [802.1p]
| ip [tos | dscp] } (1) ]
Syntax
This
command is used to set the method of which incoming packets
will be identified for the CoS to port mapping feature on the Switch.
Identified packets will be forwarded to the appropriate CoS queue.
Description
Parameters
<portlist>  Specifies a port or range of ports to be configured.
all – Specifies all ports will be configured.
none  Disable all priority-base CoS features.
ethernet  Enable Ethernet frame based priority.
802.1p  Enable 802.1p CoS
ip  Enable Ethernet frame based priority.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure port 1 as CoS-enabled:
DES-3200-28:4#config cos mapping ports 1 ethernet 802.1p
Command: config cos mapping ports 1 ethernet 802.1p
Success.
DES-3200-28:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
