xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
32
8
Example usage:
To show VLAN translation rules for C-VID 10 to C-VID 40:
DES-3200-28:4#show vlan_translation cvid 10-40
Command: show vlan_translation cvid 10-40
CVID SVID Action
---- ---- ------
10 100 Add
20 100 Add
30 200 Add
40 400 Replace
Total Entries: 4
DES-3200-28:4#
config bpdu_tunnel ports
Used to co
nfigure the BPDU tunneling port setting.
Purpose
config b
pdu_tunnel ports [<portlist> | all ] type [tunnel {stp | gvrp} | uplink | none]
Syntax
BPDU tunn
eling is used to tunnel layer 2 protocol packets. This command is used to
configure BPDU tunneling port type. When the device is operated with Q-in-Q enabled,
DA will be replaced by the tunnel multicast address, and the BPDU will be tagged with
the tunnel VLAN based on the Q-in-Q VLAN configuration and the tunnel/uplink setting.
Description
When the device is operated without Q-in-Q enabled, the BPDU will have its DA
replaced by the tunnel multicast address and be transmitted out based on the VLAN
configuration and the tunnel/uplink setting.
The tunnel multicast address for STP BPDU is 01-05-5d-00-00-00.
The tunnel multicast address for GVRP BPDU is 01-05-5d-00-00-21.
ports
- Specify the ports on which the BPDU tunneling will be enabled or disabled.
Parameters
type - Specify the type on the ports.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure BPDU tunneling tunnel ports:
DES-3200-28:4#config bpdu_tunnel ports 1-4 type tunnel stp
Command: config bpdu_tunnel ports 1-4 type tunnel stp
Success.
DES-3200-28:4#
