xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual
69
DES-3200-28:4#download cfg_fromTFTP 10.48.74.121 c:\cfg\setting.txt
Command: download cfg_fromTFTP 10.48.74.121 c:\cfg\setting.txt
Connecting to server................... Done.
Download configuration................. Done.
Success.
DES-3200-28:4#
DES-3200-28:4##-------------------------------------------------------------------
DES-3200-28:4## DES-3200-28 Configuration
DES-3200-28:4##
DES-3200-28:4## Firmware: Build 1.10.B014
DES-3200-28:4## Copyright(C) 2009 D-Link Corporation. All rights reserved.
DES-3200-28:4##-------------------------------------------------------------------
DES-3200-28:4#
DES-3200-28:4#
DES-3200-28:4## BASIC
DES-3200-28:4#
DES-3200-28:4#config serial_port baud_rate 9600 auto_logout 10_minutes
Command: config serial_port baud_rate 9600 auto_logout 10_minutes
The download configuration command will initiate the loading of the various settings in the order listed in the configuration file.
When the file has been successfully loaded the message “End of configuration file for DES-3200-28” appears followed by the
command prompt.
DES-3200-28:4#disable authen_policy
Command: disable authen_policy
Success.
DES-3200-28:4#

D-Link xStack DES-3200 Series Specifications

General

Managed	Yes
Layer	Layer 2
MAC Address Table Size	8K
Quality of Service (QoS)	802.1p
Security Features	ACL, 802.1X, Port Security
Jumbo Frame Support	Up to 9KB
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Forwarding Rate	13.1 Mpps (48-port)
