Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 4
Page 7.8.10
ESS BUS TIE
Essential bus NORM & EMER switch
BUS 1
AP SERVOS Autopilot servo protection
FLAPS Flaps protection
AIL TRIM Aileron trim protection
RUD TRIM Pitch trim protection
BUS 2
LDG GEAR Landing gear general supply protection
ESS BUS 1
ESS BUS 1 Essential bus 1 circuit protection
PFD 1 Primary Flight Display 1 protection
COM 1 VHF 1 protection
GPS/NAV 1 GPS NAV 1 protection
ADC 1 Air Data Computer 1 protection
ENGINE Powerplant cont. protec. : Oil temp. & pres., torque,
propeller
AIRFRAME 1
ENGINE Powerplant cont. protection : Ng, flowmeter & ITT
AIRFRAME 2
FUEL GAGE 1 L.H. fuel gage protection
FUEL GAGE 2 R.H fuel gage protection
ESS BUS 2
ESS BUS 2 Essential bus 2 circuit protection
PASS MASKS Passengers' oxygen masks protection
STBY INSTR Standby Attitude Module (MD302) protection
AUDIO Audio control panel protection
TOUCH CTRL 1 Touchscreen controller 1 protection
AHRS 1 Attitude and Heading Reference System 1 protection
XPDR 1 Transponder 1 protection
LDG SIG Landing gear indicating system protection
NP/NG Tachometer signal conditioner protection
FEATHER Propeller feather protection
TORQUE Torque control protection
IGNITION Powerplant iginition protection
(Cont'd on next page)
Figure 7.8.4 (1/5) - Breaker panel (Typical arrangement)
