Pilot's Operating Handbook
Section 7
Description
Edition 1 - January 15, 2018
Rev. 4
Page 7.8.11
BUS 1
AP CTRL Flight controller protection
PFD 2 Primary Flight Display 2 protection
COM 2 VHF 2 & radio protection
GPS/NAV 2 GPS NAV 2 protection
ADC 2 Air Data Computer 2 protection
STORM Stormscope protection, if installed
AIRFRAME DE ICE Empennage and wing leading edges deicing
INERT DE ICE Inertial separator protection
R WS DE ICE R.H. windshield deicing protection
PITOT L Pitot L heating protection
TOUCH CTRL 2 Touchscreen controller 2 protection
AHRS 2 Attitude and Heading Reference System 2 protection
XPDR 2 Transponder 2, if installed protection
STROBE LIGHT Strobe lights protection
SHAKER Stick shaker protection
BUS 2
PROP DE ICE Propeller deicing protection
ICE LIGHT L.H. wing leading edge lighting and lighting test protection
FLAPS SIG Trim and flaps regulator protection
CAB BLEED Cabin pressurization protection
AIR COND Cabin ventilation and vapor cycle system protection
CABIN DOORS Cabin doors opening protection
NAV/RECOG LIGHT Navigation and recognition lights protection
PLUGS 12 VDC plugs protection
PLUGS USB plugs protection
MFD Multifunction display protection
CABIN Passenger's reading lamps protection
PANEL LIGHT Instruments lighting protection
TAS TAS, if installed protection
WXR Weather radar protection
DATA LINK Data Link, if installed protection
LDG CONT Landing gear control protection
(Cont'd on next page)
Figure 7.8.4 (2/5) - Breaker panel (Typical arrangement)
