Pilot's Operating Handbook
Section 8
Handling, servicing and maintenance
Edition 1 - January 15, 2018
Rev. 4
Page 8.9.7
E - Installation of intermediate seats
1) Install intermediate seats – refer to paragraph 1 G.
2) If removed, install the baggage compartment partition net.
3) If removed, install cabin central carpet.
F - Installation of rear seats - see figure 8.9.1
1) Make sure the work area is clean and free from debris.
2) Clear the carpet from seat area to facilitate moving in rails.
3) Check that knobs (8) maintain locks (3) in up position.
4) Position the seat, fold it forward, refer to detail B, and insert pads (4)
into rail (5) apertures.
5) Move the seat so that locks (3) are in front of the color mark made on rail
bottom.
6) Pull up and hold L.H. and R.H. rings (2) and turn knobs (8) by 90° in
order to insert locks (3) into rail (5) apertures.
7) Make sure the seat is correctly locked on rails (5).
8) Tilt seat forward, hold it and slip strap (9) around the locking control
hinge pin. Screw quick links (7).
>> Airplane with seats heaters system (Post-MOD70-0588-25)
9) Open the floor hatch and remove clip from holder located under floor
panel and connect heating system harness (26). Clip connectors on
the holder located on the seat structure.
>> All
10) Tilt the seat rearward and lock it using seat tilting handle (1).
11) Fold up the backrest and lock it using backrest tilting handle (6).
12) Slide properly the carpet under the seat.
13) Remove protective covers.
G - Reconditioning
1) Make sure the work area is clean and free from debris.
2) Determine weight and balance - refer to section 6.
