Pilot's Operating Handbook
Section 8
Handling, servicing and maintenance
Edition 1 - January 15, 2018
Rev. 4
Page 8.9.6
2 -- Conversion of 4-seat accommodation into 6-seat accommodation - see
figures 8.9.1, 8.9.2, 8.9.3 and 8.9.4
A - Tools and consumable materials
- Seat protective covers
B - Preparation
1) Make sure the SOURCE selector is set to OFF and the crash lever is
down.
2) If installed, remove the cargo net.
3) Remove intermediate seats – refer to paragraph 1.D.
4) Remove the deflectors (34) maintained with Velcro-type strap.
5) If necessary, remove the cabin central carpet.
C - Cabin comfort - see figure 8.9.3
1) Remove blanking plugs (32) from their storage bag and install them on
holes located forward the large door - see figure 8.9.3 detail B.
2) Remove blanking device assy (33) from the hot air outlet, located
forward the large door, and store it into storage bag - see figure 8.9.3
detail A.
3) Remove blanking plugs (31) located in line with card table - see
figure 8.9.3 detail D, and install them on holes located in line with R.H.
front side window - see figure 8.9.3 detail C.
● NOTE ●
Should long term changes be made to cabin configuration (4 / 6 seats), cabin
upholstery blanking device and plug arrangements will need to be reconfigured
in order to optimize the temperature conditioning system.
Subject changes should preferably be performed at a recognized service
center.
●
D - Installation of cabinet
● NOTE ●
This operation must be carried out by a service center.
●
