Daikin ACS320 - Drive Parameter Backup Mode

Drive Parameter Backup Mode
Use the parameter backup mode to export parameters from
one drive to another. The parameters are uploaded from a
drive to the control panel and downloaded from the control
panel to another drive. Two options are available:
Par Backup Mode
The Assistant Control Panel can store a full set of drive
parameters.
The Par Backup mode has these functions:
• Upload to Panel – Copies all parameters from the
drive to the Control Panel. This includes user sets of
parameters (if dened) and internal parameters such as
those created by the Motor Id Run. The Control Panel
memory is non-volatile and does not depend on the
panel’s battery.
Figure 13: Changing the Drive Parameter Backup
To upload parameters to control panel, follow these steps:
1
Select MENU to enter the main menu.
2
Select PAR BACKUP with the UP/DOWN buttons and select ENTER.
3
Scroll to Upload to Panel and select SEL.
4
The text “Copying parameters” and a progress diagram is displayed.
Select ABORT if you want to stop the process
5
The text “Parameter upload successful” is displayed and the control panel
returns to the PAR BACKUP menu. Select EXIT to return to the main menu.
Now you can disconnect the panel.
