Download Application – Copies a partial parameter set from
the Control Panel to a drive. The partial set does not include
internal motor parameters, parameters 9905…9909, 1605,
1607, 5201, nor any Group 51 and 53 parameters. Use this
option to transfer parameters to systems that use similar
congurations – the drive and motor sizes do not need to be
the same.
• Download User Set 1 - Copies USER S1 parameters
(user sets are saved using parameter 9902 APPLIC
MACRO) from the Control Panel to the drive.
• Download User Set 2 - Copies USER S2 parameters
from the Control Panel to the drive.
Figure 15: Downloading Applications
To download application to drive, follow these steps:
1
Select MENU to enter the main menu.
2
Select PAR BACKUP with the UP/DOWN buttons.
3
Scroll to DOWNLOAD APPLICATION and select SEL..
4
The text “Downloading parameters (partial)” is displayed.
Select ABORT if you want to stop the process.
5
The text “Parameter download successful” is displayed and the control panel
returns to PAR BACKUP menu. Select EXIT to return to the main menu.
OM 1190-1 • MD4 VFD 20 www.DaikinApplied.com
sTarT up
