Introduction SiE33-102
130 Installation Manual
1.3 Combination
The combination with indoor units is as follows:
The possible combination of the outdoor unit with indoor units is in function of the total capacity index of
these indoor units and must be within the range as specified below:
Up to 20 indoor units can be connected to 1 outdoor unit RSXY16,18 and 20.
Up to 32 indoor units can be connected to 1 outdoor unit RSXY24,26,28 and 30.
Refer to the catalogue and/or engineering data book for model numbers of indoor units which can be
connected.
Outdoor Unit
RSXY16 < RXY8 + RXE8 >...................................................................................... 200 - 520
RSXY18 < RXY10 + RXE8 >.................................................................................... 225 - 585
RSXY20 < RXY10 + RXE10 >.................................................................................. 250 - 650
RSXY24 < RXY16 + RXE8 >.................................................................................... 300 - 780
RSXY26 < RXY16 + RXE10 >.................................................................................. 325 - 845
RSXY28 < RXY20 + RXE8 >.................................................................................... 350 - 910
RSXY30 < RXY20 + RXE10 >.................................................................................. 375 - 975
Si33-102.book Page 130 Tuesday, June 26, 2001 3:18 PM
