Test Operation SiE33-102
86 General Information
4.12.4 Setting Contents and Code No. – VRV Unit
Notes: 1. Setting is carried out in the group mode. however, if the mode number inside the parentheses is
selected, indoor units can also be set individually.
2. The SECOND CODE number. is set to “ ” when shipped from the factory.
3. Do not make any settings not given in the table above.
4. Not displayed if the indoor unit is not equipped with that function.
5. When returning to the normal mode. “88” may be displayed in the LCD in order for the remote control to
initialize itself.
Mode No.
Note)1
FIRST
CODE No.
Description of Setting
SECOND CODE NO. Note)2
01 02 03 04
10(20)
0
Filter Contamination-Heavy/
Light (Setting for display time
to clean air filter) (Sets display
time to clean air filter to half
when there is heavy filter
contamination.)
Ultra-Long-Life
Type
Light
Approx.
10,000
hours
Heavy
Approx.
5,000
hours
——
Long-Life Type
Approx.
2,500
hours
Approx.
1,250
hours
Standard Type
Approx.
200 hours
Approx.
100 hours
1
Long-life filter type (Setting of filter sign indication
time) (Change setting when Ultra-long-life filter is
installed)
Long-Life
Filter
Ultra-Long-
Life Filter
——
2 Thermostat Sensor in Remote Control Use Not Use — —
3
Display Time to Clean Air Filter Calculation (Set
when filter sign is not to be displayed)
Display
Do not
Display
——
12(22)
0
Optional accessories output selection (field
selection of output for adaptor for wiring)
Indoor Unit
Turned ON by
Thermostat
—
Operation
Output
Malfunction
Output
1
ON/OFF Input from Outside (Set when ON/OFF is
to be controlled from outside.)
Forced Off
ON/OFF
Control
External
Protection
Device
—
2
Thermostat Differential Changeover (Set when
remote sensor is to be used.)
FXYC, FXYF, FXYK, FXYH only
1˚C 0.5˚C — —
4
Automatic mode differential (automatic
temperature differential setting for VRV system
heat recovery series cool/heat)
01 : 0 02 : 1 03 : 2 04 : 3 05 : 4 06 : 5 07 : 6 08 : 7
5 Power failure automatic reset (Auto Restart) No equipped Equipped — —
13(23)
0
High Air Outlet Velocity (Set when installed in a
place with ceiling higher than 2.7m.)
NH——
1
Selection of Air Flow Direction (Set when a
blocking pad kit has been installed) FXYF only
F
(4 directions)
T
(3 directions)
W
(2 directions)
—
3
Air Flow Direction Adjustment (Set at installation of
decoration panel.) FXYK only
Equipped Not Equipped — —
4 Field set air flow position setting
Draft
Prevention
Standard
Ceiling Soiling
Prevention
—
5
Field set fan speed selection (fan speed control by
air discharge outlet for phase control)
Standard
Optional
Accessory 1
Optional
Accessory 2
—
15(25)
1 Humidifying with thermostat OFF Not Equipped Equipped — —
3 Drain Pump humidifier interlock selection Not Equipped Equipped — —
