SiE33-102 Product Outline
General Information 5
1.3 Model Configuration and Combination
Number of units and capacity of connectable indoor units
Y1 : 3 phase, 380~415V, 50Hz
YAL : 3 phase, 380V, 60Hz
(E) : Salt damage resistant specifications
Connectable indoor unit
VE : 1 phase, 220~240V/220V, 50/60Hz
V1 : 1 phase, 220~240V, 50Hz
VAL : 1 phase, 220V, 60Hz
Indoor unit capacity
Use the above tables to determine the capacities of indoor units to be connected. Make sure the total
capacity of indoor units connected to each outdoor unit is within the specified value (kW).
The total capacity of connected indoor units must be within a range of 50 to 130% of the rated capacity
of the outdoor unit.
In some models, it is not possible to connect the maximum number of connectable indoor units. Select
models so the total capacity of connected indoor units conforms to the specification.
Standard
series
Equivalent output 16HP 18HP 20HP 24HP
R-22 VRV PLUS series system model RSXY16KAY1(E)/
YAL(E)
RSXY18KAY1(E)/
YAL(E)
RSXY20KAY1(E)/
YAL(E)
RSXY24KAY1(E)/
YAL(E)
Outdoor unit combination Main unit RXY8KAY1(E)/
YAL(E)
RXY10KAY1(E)/
YAL(E)
RXY10KAY1(E)/
YAL(E)
RXY16KAY1(E)/
YAL(E)
Sub unit RXE8KAY1(E)/
YAL(E)
RXE8KAY1(E)/
YAL(E)
RXE10KAY1(E)/
YAL(E)
RXE8KAY1(E)/
YAL(E)
Total number of connectable indoor units Up to 20 units Up to 32 units
Total capacity of connectable indoor units 200~520 225~585 250~650 300~780
Standard
series
Equivalent output 26HP 28HP 30HP
R-22 VRV PLUS series system model RSXY26KAY1(E)/
YAL(E)
RSXY28KAY1(E)/
YAL(E)
RSXY30KAY1(E)/
YAL(E)
Outdoor unit combination Main unit RXY16KAY1(E)/YAL(E) RXY20KAY1(E)/YAL(E) RXY20KAY1(E)/YAL(E)
Sub unit RXE10KAY1(E)/YAL(E) RXE8KAY1(E)/YAL(E) RXE10KAY1(E)/YAL(E)
Total number of connectable indoor units Up to 32 units
Total capacity of connectable indoor units 325~845 350~910 375~975
Indoor unit Model name
Ceiling
mounted
cassette unit
2-way blow FXYC20KVE·25KVE·32KVE·40KVE·50KVE·63KVE·80KVE·125KVE
4-way blow FXYF25KBVE·32KBVE·40KBVE·50KBVE·63KBVE·80KBVE·100KBVE·125KBVE
Corner type FXYK25KV1/VAL·32KV1/VAL·40KV1/VAL·63KV1/VAL
Ceiling mounted low silhoutte duct
unit
FXYD20KAVE·25KAVE·32KAVE·40KAVE·50KAVE·63KAVE
Concealed ceiling unit FXYS20KV1/VAL·25KV1/VAL·32KV1/VAL·40KV1/VAL·50KV1/VAL·63KV1/VAL·80KV1/VAL·100KV1/
VAL·125KV1/VAL
Concealed ceiling unit FXYB20KV1·25KV1·32KV1·40KV1·50KV1·63KV1·80KV1·100KV1·125KV1·
Concealed ceiling unit (large) FXYM40KVE·50KVE·63KVE·80KVE·100KVE·125KVE·200KJVE·250KJVE
Ceiling suspended unit FXYH32KVE·63KVE·100KVE
Wall mounted unit FXYA25KVE·32KVE·40KVE·50KVE·63KVE
Floor standing unit FXYL20KJVE·25KJVE·32KJVE·40KJVE·50KJVE·63KJVE
Concealed floor standing unit FXYLM20KJVE·25KJVE·32KJVE·40KJVE·50KJVE·63KJVE
New refrigerant model code 20 type 25 type 32 type 40 type 50 type 63 type 80 type 100 type 125 type 200 type 250 type
Selecting model capacity 2.2kW 2.8kW 3.5kW 4.5kW 5.6kW 7.0kW 9.0kW 11.2kW 14.0kW 22.4kW 28.0kW
Equivalent output 0.8HP 1HP 1.25HP 1.6HP 2.0HP 2.5HP 3.2HP 4HP 5HP 8HP 10HP
