SiE33-102 Field Wiring
Installation Manual 155
7.4 Power Circuit and Cable Requirements
A power circuit (See table below) must be provided for connection of the unit. This circuit must be protected
with the required safety devices, i.e. a main switch, a slow blow fuse on each phase and an earth leak
detector.
When using residual current operated circuit breakers, be sure to use a high-speed type 200mA rated
residual operating current.
Note: Select the power supply cable in accordance with relevant local and national regulations.
Phase and
Frequency
Voltage Recommended
Fuses
Transmission
Line Selection
RSXY16KAY1 3N~50Hz 380-415V 45A 0.75-1.25mm²
RSXY18KAY1 3N~50Hz 380-415V 50A 0.75-1.25mm²
RSXY20KAY1 3N~50Hz 380-415V 60A 0.75-1.25mm²
RSXY24KAY1 3N~50Hz 380-415V 60A 0.75-1.25mm²
RSXY26KAY1 3N~50Hz 380-415V 70A 0.75-1.25mm²
RSXY28KAY1 3N~50Hz 380-415V 70A 0.75-1.25mm²
RSXY30KAY1 3N~50Hz 380-415V 70A 0.75-1.25mm²
Phase and
Frequency
Voltage Recommended
Fuses
Transmission
Line Selection
RSXY16KAYAL 3N~60Hz 380V 45A 0.75-1.25mm²
RSXY18KAYAL 3N~60Hz 380V 50A 0.75-1.25mm²
RSXY20KAYAL 3N~60Hz 380V 60A 0.75-1.25mm²
RSXY24KAYAL 3N~60Hz 380V 60A 0.75-1.25mm²
RSXY26KAYAL 3N~60Hz 380V 70A 0.75-1.25mm²
RSXY28KAYAL 3N~60Hz 380V 70A 0.75-1.25mm²
RSXY30KAYAL 3N~60Hz 380V 80A 0.75-1.25mm²
Si33-102.book Page 155 Tuesday, June 26, 2001 3:18 PM
