Daikin VRV System R-22 PLUS Series User Manual

Introduction SiE33-102
132 Installation Manual
1.5 Standard Supplied Accessories
Accessories are attached in the main unit , RXY.
RSXY16,18,20
RSXY24,26,28,30
Accessories are attached in the sub unit, RXE (only-KAY1(E))
(1)
(2)
RXY8,10
(3)
(1)
(2)
RXY16,20
(1)
RXE8,10
(V1833)
Tie-Wrap (1) 9
Gas Side Attached Pipe (2)
(for connecting main and sub unit)
1
Gas Side Attached Pipe (2) 1
Gas Side Attached Pipe (2)
(for bottom piping)
1
Connection Cable : Low Voltage (2) 1
Connection Cable : High Voltage (2) 1
Installation Manual (1) 1
Operation Manual (1) 1
Product Quality Certificate (1) 1 (only KAY1(E))
Tie-Wrap (1) 11
Gas Side Attached Pipe (2)
(for connecting main and sub unit)
1
Gas Side Attached Pipe (2)
(for connecting main and sub unit)
1
Gas Side Attached Pipe (2)
(for front-piping)
1
Liquid Side Attached Pipe (2)
(for front-piping)
Do not use for RSXYP24
1
Connection Cable : Low Voltage (3) 1
Connection Cable : High Voltage (3) 1
Installation Manual (1) 1
Operation Manual (1) 1
Product Quality Certificate (1) 1 (only-KAY1(E))
Product Quality Certificate (1) 1 (only-KAY1(E))
(V0889)
(V0890)
(V0892)
(V0893)
(V0894)
(V0895)
(V0889)
(V0890)
(V0893)
(V0896)
(V0897)
(V0894)
(V0895)
