Field Wiring SiE33-102
152 Installation Manual
7.2 Internal Wiring – Parts Table
Refer to the wiring diagram sticker on the unit. The abbreviations used are listed below:
RSXY16, 18, 20
Refer “Wiring diagrams” for outdoor unit on page 116, 117.
A1P Printed circuit board (MAIN) L1R Reactor
A2P Printed circuit board (INV) M1C,2C Motor (compressor)
A3P Printed circuit board (SUB) MF1,2F Motor (fan)
A5P Printed circuit board MF3,4F Motor (fan)
BS1-5 Push button switch (MODE, SET, RETURN, Q1M,2M Thermo switch (M1F, M2F)
WIRING CHECK, RESET) Q3M,4M Thermo switch (M3F, M4F)
C1R-4R Capacitor R1 Resistor
C5R,6R Capacitor R66-69 Resistor
CN-1,CN-19 Relaying connector R93,94 Resistor
F2C Over current relay (M2C) R1T Thermistor (AIR) (A1P)
F1S Surge Absorber R1T Thermistor (FIN) (A2P)
F1U,2U Fuse (250V,10A) (A1P) R2-1T,2T Thermistor (coil)
F1U Fuse (250V,10A) (A3P) R3-1T,2T Thermistor (discharge)
H1P-7P Pilotlamp (service monitor - orange) (A1P) R4-1T,2T Thermistor (header)
H2P ; Prepare-flickering R6-1T Thermistor (suction)
Malfunction detection-light up SENPH Pressure sensor (high)
H1P-4P Pilotlamp (service monitor - red) (A2P) SENPL Pressure sensor (low)
HAP Pilotlamp
(service monitor - green) (A1P-3P)
S1PH,2PH Pressure switch (high)
INV Inverter TB1,2 Terminal circuit board (relay)
J1HC,2HC Crankcase heater T1R,2R Transformer (220-240V/22V)
K1M,2M Magnetic contactor (M1C,2C) X1M Terminal strip (power)
K1R Magnetic relay (M1F) (A1P) X2M Terminal strip (control)
K1R Magnetic relay (A2P) Y1E,2E Electronic expansion valve
K2R Magnetic relay (M1F) (A1P) Y1R 4 way valve
K2R Magnetic relay (A2P) Y1S Solenoid valve (auxiliary condenser)
K3R Magnetic relay (M2F) (A1P) Y2S Solenoid valve (hotgas)
K4R Magnetic relay (K2M) (A1P) Y3S Solenoid valve (injection M1C)
K5R Magnetic relay (A3P) Y4S Solenoid valve (injection M2C)
K6R Magnetic relay (J1HC) (A1P) Y5S Solenoid valve (receiver)
K6R Magnetic relay (M3F) (A3P) Z1F-5F Noise filter
K7R Magnetic relay (Y1R) (A1P) Diode module
K7R Magnetic relay (M4F) (A3P) Power circuit
K8R Magnetic relay (Y1S) (A1P) Power module
K9R Magnetic relay (Y2S) (A1P) Phase reversal detect circuit
K10R Magnetic relay (Y3S) (A1P) Safety devices input
K11R Magnetic relay (Y4S) (A1P)
K12R Magnetic relay (Y5S) (A1P)
D M
P C
P M
PRC
S D
