Daikin VRV System R-22 PLUS Series User Manual

Introduction SiE33-102
136 Installation Manual
1.8 Electrical Specifications
Model
RSXY16
KAY1
RSXY18
KAY1
RSXY20
KAY1
RSXY24
KAY1
RSXY26
KAY1
RSXY28
KAY1
RSXY30
KAY1
Power
Supply
- Phase 3N~ 3N~ 3N~ 3N~ 3N~ 3N~ 3N~
- Frequency Hz 50 50 50 50 50 50 50
- Voltage V 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415
- Voltage Tolerance % + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10
- Recommended
Fuses
A 45 50 60 60 70 70 70
Compressor
- Phase 3~ 3~ 3~ 3~ 3~ 3~ 3~
- Frequency Hz 50 50 50 50 50 50 50
- Voltage V 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415 380 – 415
Control and
Fan Motor
- Phase 1~ 1~ 1~ 1~ 1~ 1~ 1~
- Frequency Hz 50 50 50 50 50 50 50
- Voltage V 220 – 240 220 – 240 220 – 240 220 – 240 220 – 240 220 – 240 220 – 240
- Nominal Running
Current
A 4.5 4.5 4.5 6.7 6.7 6.7 6.7
Model
RSXY16
KAYAL
RSXY18
KAYAL
RSXY20
KAYAL
RSXY24
KAYAL
RSXY26
KAYAL
RSXY28
KAYAL
RSXY30
KAYAL
Power
Supply
- Phase 3N~ 3N~ 3N~ 3N~ 3N~ 3N~ 3N~
- Frequency Hz 60 60 60 60 60 60 60
+0 V 380 380 380 380 380 380 380
- Voltage Tolerance % + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10 + 6 / – 10
- Recommended
Fuses
A 45 50 60 60 70 70 80
Compressor
- Phase 3~ 3~ 3~ 3~ 3~ 3~ 3~
- Frequency Hz 60 60 60 60 60 60 60
- Voltage V 380 380 380 380 380 380 380
Control and
Fan Motor
- Phase 1~ 1~ 1~ 1~ 1~ 1~ 1~
- Frequency Hz 60 60 60 60 60 60 60
- Voltage V 220 220 220 220 220 220 220
- Nominal Running
Current
A 6.0 6.0 6.0 9.0 9.0 9.0 9.0
