Test Operation SiE33-102
90 General Information
BRC7C(4C) Type
(BRC4C Type :
without auto swing)
Group No. setting by infrared remote for centralized control
1. When in the normal mode, push button for 4 seconds or more, and operation then enters the
“field set mode.”
2. Set mode No. “00” with button.
3. Set the group No. for each group with button (advance/backward).
4. Enter the selected group numbers by pushing button.
5. Push button and return to the normal mode.
BRC7C (4C) Type
Group No. Setting
Example
If you have to set the address for each unit for calculating cost, etc., set the mode No. to “30.”
Caution When turning the power supply on, the unit may often not accept any operation while "88" is displaying
after all indications were displayed once for about 1 minute on the liquid crystal display.
This is not an operative fault.
Central Remote
Control
F1 F2
F1 F2 F1 F2
F1 F2
P1 P2
RC
RC
RC RC RC
F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2
F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2
No Remote Control
Group Control by Remote Control
(automatic unit address)
1-03
1-00
1-01
Main Sub
1-02
1-04
Indoor/Outdoor
Outdoor/Outdoor
F1 F2 F1 F2
Indoor/Outdoor
Outdoor/Outdoor
(V1567)
Si33-102.book Page 90 Tuesday, June 26, 2001 3:18 PM
