SiE33-102 Introduction
Installation Manual 135
1.7 Technical Specifications
“KAY1” for 3N~380-415V 50Hz “KAYAL” for 3N~380V 60Hz
General RSXY16 RSXY18 RSXY20 RSXY24 RSXY26 RSXY28 RSXY30
Nominal Cooling Capacity kW 44.8 50.4 56.0 67.2 72.8 78.4 84.0
Nominal Heating Capacity kW 50.0 56.5 63.0 75.0 81.5 88.0 94.5
Nominal Input Cooling/Heating kW 16.9 / 15.6 19.2 / 17.6 21.3 / 19.6 26.3 / 22.7 28.7 / 24.7 30.7 / 26.7 32.8 / 28.7
Dimensions
HxWxD
Main Unit mm
1440×1280
×690
1440×1280
×690
1440×1280
×690
1450×2580
×690
1450×2580
×690
1450×2580
×690
1450×2580
×690
Sub Unit mm
1220×1280
×690
1220×1280
×690
1440×1280
×690
1220×1280
×690
1440×1280
×690
1220×1280
×690
1440×1280
×690
Weight
Main Unit kg 365 370 370 625 625 635 635
Sub Unit kg 95 95 105 95 105 95 105
Connections
Refrigerant Gas Inlet
inch 1 3/8 OD 1 3/8 OD 1 3/8 OD 1 5/8 OD 1 5/8 OD 1 5/8 OD 1 5/8 OD
mm 34.9 34.9 34.9 41.3 41.3 41.3 41.3
Refrigerant Liquid
Inlet
inch 5/8 flare 6/8 flare 6/8 flare 6/8 flare 7/8 OD 7/8 OD 7/8 OD
mm 15.9 19.1 19.1 19.1 22.2 22.2 22.2
Refrigerant Gas Inlet
for Sub Units
inch 1 OD 1 OD 1 OD 1 OD 1 OD 1 OD 1 OD
mm 25.4 25.4 25.4 25.4 25.4 25.4 25.4
Refrigerant Liquid
Inlet for Sub Units
inch 1/2 flare 1/2 flare 1/2 flare 1/2 flare 1/2 flare 1/2 flare 1/2 flare
mm 12.7 12.7 12.7 12.7 12.7 12.7 12.7
(1) Refer to the engineering data book for the complete list of specifications.
(2) The nominal cooling capacity is based on: - indoor temperature: 27˚CDB/19˚CWB
- outdoor temperature: 35˚CDB
- pipe length: 5m
- level difference: 0m
(3)The nominal heating capacity is based on: - indoor temperature: 20°CDB
- outdoor temperature: 7°CDB/6°CWB
- pipe length: 5m
- level difference: 0m
(4) The nominal input includes total input of the unit: compressor, fan motor and control circuit.
Compressor RSXY16KAY1 RSXY18KAY1 RSXY20KAY1 RSXY24KAY1 RSXY26KAY1 RSXY28KAY1 RSXY30KAY1
Model
JT236D-VTYE
+
JT212D-TYE
JT236D-VTYE
+
JT265D-TYE
JT236D-VTYE
+
JT265D-TYE
JT236D-VTYE
+
JT236D-TYE
+
JT236D-TYE
JT236D-VTYE
+
JT236D-TYE
+
JT236D-TYE
JT236D-VTYE
+
JT300D-TYE
+
JT300D-TYE
JT236D-VTYE
+
JT300D-TYE
+
JT300D-TYE
Oil Type
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
Oil Charge Volume l 4.0 + 4.0 4.0 + 4.0 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0
Crankcase Heater W 50 + 50 50 + 50 50 + 50 50 + 50 + 50 50 + 50 + 50 50 + 50 + 50 50 + 50 + 50
Refrigerant Type R-22 R-22 R-22 R-22 R-22 R-22 R-22
Refrigerant Charge kg 18.6 19.7 19.7 27.0 27.0 29.2 29.2
Condenser RSXY16KAY1 RSXY18KAY1 RSXY20KAY1 RSXY24KAY1 RSXY26KAY1 RSXY28KAY1 RSXY30KAY1
Nominal Air Flow m
3
/min 320 320 340 490 510 490 510
Fan Motor Output W 140 × 2,230 × 2 140 × 2,230 × 2 140 × 2,230 × 2 140 × 3,230 × 3 140 × 3,230 × 3 140 × 3,230 × 3 140 × 3,230 × 3
Compressor RSXY16KAYAL RSXY18KAYAL RSXY20KAYAL RSXY24KAYAL RSXY26KAYAL RSXY28KAYAL RSXY30KAYAL
Model
JT236D-VTYE
+
JT212D-TYH
JT236D-VTYE
+
JT265D-TYH
JT236D-VTYE
+
JT265D-TYH
JT236D-VTYE
+
JT236D-TYH
+
JT236D-TYH
JT236D-VTYE
+
JT236D-TYH
+
JT236D-TYH
JT236D-VTYE
+
JT300D-TYH
+
JT300D-TYH
JT236D-VTYE
+
JT300D-TYH
+
JT300D-TYH
Oil Type
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
SUNISO
4GSDID-K
Oil Charge Volume l 4.0 + 4.0 4.0 + 4.0 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0 4.0 + 4.0 + 4.0
Crankcase Heater W 50 + 50 50 + 50 50 + 50 50 + 50 + 50 50 + 50 + 50 50 + 50 + 50 50 + 50 + 50
Refrigerant Type R-22 R-22 R-22 R-22 R-22 R-22 R-22
Refrigerant Charge kg 18.6 19.7 19.7 27.0 27.0 29.2 29.2
Condenser RSXY16KAYAL RSXY18KAYAL RSXY20KAYAL RSXY24KAYAL RSXY26KAYAL RSXY28KAYAL RSXY30KAYAL
Nominal Air Flow m
3
/min 320 320 340 490 510 490 510
Fan Motor Output W 140 × 2,230 × 2 140 × 2,230 × 2 140 × 2,230 × 2 140 × 3,230 × 3 140 × 3,230 × 3 140 × 3,230 × 3 140 × 3,230 × 3
Si33-102.book Page 135 Tuesday, June 26, 2001 3:18 PM
