Daikin VRV System R-22 PLUS Series User Manual

SiE33-102 Field Wiring
Installation Manual 153
RSXY24, 26, 28, 30
A1P Printed circuit board (MAIN) Q11M,12M Thermo switch (M11F, M12F)
A2P Printed circuit board (INV) Q21M,22M Thermo switch (M21F, M22F)
A3P,4P Printed circuit board (SUB) Q3M,4M Thermo switch (M3F, M4F)
A5P Printed circuit board R1 Resistor
BS1-5 Push button switch (MODE, SET, RETURN, R66-69 Resistor
WIRING CHECK, RESET) R93,94 Resistor
C11R,12R Capacitor R1T Thermistor (AIR) (A1P)
C21R,22R Capacitor R1T Thermistor (FIN) (A2P)
C3R,4R Capacitor R2-11T,12T Thermistor (coil)
C5R,6R Capacitor R2-2T Thermistor (coil)
CN-1,CN-19 Relaying connector R3-11T-13T Thermistor (discharge)
F1S Surge Absorber R4-11T-13T Thermistor (header)
F2C,3C Over current relay (M2C,3C) R6-1T Thermistor (suction)
F1U,2U Fuse (250V,10A) (A1P) SENPH Pressure sensor (high)
F1U Fuse (250V,10A) (A3P,4P) SENPL Pressure sensor (low)
H1P-7P Pilotlamp (service monitor - orange) (A1P) S1PH-3PH Pressure switch (high)
H2P ; Prepare-flickering TB1,2 Terminal circuit board (relay)
Malfunction detection-light up T1R,2R Transformer (220-240V/22V)
H1P-4P Pilotlamp (service monitor - red) (A2P) X1M Terminal strip (power)
HAP Pilotlamp (service monitor - green) (A1P-4P) X2M Terminal strip (control)
INV Inverter X3M Terminal strip (relay)
J1HC-3C Crankcase heater Y1E-3E Electronic expansion valve
K1M,3M Magnetic contactor (M1C,2C,3C) Y1R 4 way valve
K1R Magnetic relay (M11F) (A1P) Y1S Solenoid valve (auxiliary condenser)
K1R Magnetic relay (A2P) Y2S Solenoid valve (hotgas)
K1R Magnetic relay (Y6S) (A3P) Y3S Solenoid valve (injection M1C)
K2R Magnetic relay (M11F) (A1P) Y4S Solenoid valve (injection M2C)
K2R Magnetic relay (A2P) Y5S Solenoid valve (receiver)
K3R Magnetic relay (M12F) (A1P) Y6S Solenoid valve (injection M3C)
K4R Magnetic relay (K2M) (A1P) Z1F-6F Noise filter(surge absorber)
K5R Magnetic relay (K3M) (A1P) Diode module
K5R Magnetic relay (A3P,A4P) Power circuit
K6R Magnetic relay (J1HC) (A1P) Power module
K6R Magnetic relay (M21F) (A3P) Phase reversal detect circuit
K6R Magnetic relay (M3F) (A4P) Safety devices input
K7R Magnetic relay (Y1R) (A1P)
K7R Magnetic relay (M22F) (A3P) Field wiring
K7R Magnetic relay (M4F) (A4P) L1,L2,L3 Live
K8R Magnetic relay (Y1S) (A1P) N Neutral
K9R Magnetic relay (Y2S) (A1P) Connector
K10R Magnetic relay (Y3S) (A1P) Wire clamp
K11R Magnetic relay (Y4S) (A1P) Protective earth (screw)
K12R Magnetic relay (Y5S) (A1P) Colours BLK : Black
BLU : Blue
BRN : Brown
GRY : Gray
ORG : Orange
PNK : Pink
RED : Red
WHT : White
YLW : Yellow
L1R Reactor
M1C,2C,3C Motor (compressor)
MF11,12F Motor (fan)
MF21,22F Motor (fan)
MF3,4F Motor (fan)
D M
P C
P M
PRC
S D
Si33-102.book Page 153 Tuesday, June 26, 2001 3:18 PM
