Xtium2-CLHS PX8 User's Manual Xtium2-CLHS PX8 Reference • 63
CORACQ_PRM_FLAT_FIELD_PIXEL_REPLA
CEMENT
_METHOD
CORACQ_VAL_FLAT_FIELD_PIXEL_REPLACEMENT_METHOD_2
(Pixel replacement is done by averaging the 2 neighborhood pixels. When one
of the neighbors is not available (border image pixels, the pixel is simply
replaced with the available neighbor)
CORACQ_VAL_FLAT_FIELD_PIXEL_REPLACEMENT_METHOD_3
(Pixel replacement is done by averaging neighborhood pixels using a 3x2
kernel)
CORACQ_PRM_FLAT_FIELD_SET_SELECT
min = 0
max = 16
step = 1
CORACQ_PRM_TIME_STAMP Available
CORACQ_CAP_SERIAL_PORT_INDEX Not Available
CORACQ_PRM_IMAGE_FILTER_ENABLE Not Available
CORACQ_PRM_SHAFT_ENCODER_REVERSE_COUNT Max = 65536 ticks
CORACQ_PRM_META_DATA CORACQ_VAL_META_DATA_PER_LINE_RIGHT (0x2)
Transfer Related Capabilities
Capability Values
CORXFER_CAP_NB_INT_BUFFERS CORXFER_VAL_NB_INT_BUFFERS_AUTO (0x2)
CORXFER_CAP_MAX_XFER_SIZE 4294967040 Bytes
CORXFER_CAP_MAX_FRAME_COUNT 16777215 Frames
CORXFER_CAP_COUNTER_STAMP_AVAILABLE FALSE
Transfer Related Parameters
Parameter Values
CORXFER_PRM_EVENT_TYPE
CORXFER_PRM_EVENT_TYPE_EX
CORXFER_VAL_EVENT_TYPE_START_OF_FRAME
CORXFER_VAL_EVENT_TYPE_END_OF_FRAME
CORXFER_VAL_EVENT_TYPE_END_OF_LINE
CORXFER_VAL_EVENT_TYPE_END_OF_NLINES
CORXFER_VAL_EVENT_TYPE_END_OF_TRANSFER
CORXFER_PRM_START_MODE
CORXFER_VAL_START_MODE_ASYNCHRONOUS (0x0)
CORXFER_VAL_START_MODE_SYNCHRONOUS (0x1)
CORXFER_VAL_START_MODE_HALF_ASYNCHRONOUS (0x2)
CORXFER_VAL_START_MODE_SEQUENTIAL (0x3)
CORXFER_PRM_CYCLE_MODE
CORXFER_VAL_CYCLE_MODE_ASYNCHRONOUS (0x0)
CORXFER_VAL_CYCLE_MODE_SYNCHRONOUS_WITH_TRASH (0x2)
CORXFER_VAL_CYCLE_MODE_OFF (0x3)
CORXFER_VAL_CYCLE_MODE_SYNCHRONOUS_NEXT_EMPTY_WITH_TRASH (0x5)
CORXFER_PRM_FLIP
CORXFER_VAL_FLIP_OFF (0x0)
CORXFER_VAL_FLIP_VERT (0x2)
CORXFER_PRM_INT_BUFFERS * Depends on acquired image size.
By default driver will optimize the number of on-board buffers.
CORXFER_PRM_EVENT_COUNT_SOURCE
CORXFER_VAL_EVENT_COUNT_SOURCE_DST (0x1)
CORXFER_VAL_EVENT_COUNT_SOURCE_SRC (0x2)
CORXFER_PRM_BUFFER_TIMESTAMP_MODULE
CORXFER_VAL_BUFFER_TIMESTAMP_MODULE_ACQ (0x1)
CORXFER_VAL_BUFFER_TIMESTAMP_MODULE_XFER (0x13)
CORXFER_PRM_BUFFER_TIMESTAMP_EVENT (ACQ
Related)
CORACQ_VAL_EVENT_TYPE_START_OF_FRAME (0x80000)
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER (0x1000000)
CORXFER_PRM_BUFFER_TIMESTAMP_EVENT (XFER
Related)
CORXFER_VAL_EVENT_TYPE_END_OF_FRAME (0x800000)
CORXFER_PRM_LINE_MERGING
CORXFER_VAL_LINE_MERGING_AUTO (0x0)
CORXFER_VAL_LINE_MERGING_OFF (0x2)
