Dalsa Xtium2-CLHS PX8 User Manual

76 • Technical Specifications Xtium2-CLHS PX8 User's Manual
Status LEDs Functional Descriptions
Three LED indicators, mounted on the board bracket, provide information on board and connection
status as per the tables below.
D1: Boot-up/PCIe Status LED — Provides general board status information
D3: Camera Link HS status LED — Indicates data status for J3 when connected to a camera or
when receiving forwarded data from another Xtium2-CLHS system.
D6: Camera Link HS Forwarded Data status LED — Indicates connection status when the data
forwarding connector J2 is connected to another Xtium2-CLHS.
D1: Boot-up/PCIe Status LED
Color State Description
Red Solid FPGA firmware not loaded
Green Solid Normal FPGA firmware loaded, Gen3 speed, link width x8
Green Flashing Normal FPGA firmware loaded, Gen1/Gen2 speed, link width x8
Y
Y
Y
e
e
e
l
l
l
l
l
l
o
o
o
w
w
w
Solid Normal FPGA firmware loaded, Gen3 speed, link width not x8
Y
Y
Y
e
e
e
l
l
l
l
l
l
o
o
o
w
w
w
Flashing Normal FPGA firmware loaded, Gen1/Gen2 speed, link width not x8
Blue Solid Safe FPGA firmware loaded, Gen3 speed
Blue Flashing Safe FPGA firmware loaded, Gen1/Gen2 speed
Red Flashing PCIe Training Issue – Board will not be detected by computer
D3: Camera Link HS Status LED (when a camera is connected)
The Xtium2-CLHS PX8 implements the mandatory LED states defined by the Camera Link HS
Specification v1.0 RC5. The first column – Priority, defines the signaling order when multiple events
are reported simultaneously.
This LED status table reflects activity on input connector J3 when a camera is connected (i.e. the
Xtium2 is the Data Forwarding Master).
Priority LED State State Name Description
A Off NON_OP
Device not powered and/or waiting for
software; No Hardware or the LED was
commanded to the off state.
3
Constant
Orange
FAR_END_RESET
The device at the Far End is holding this
device in reset preventing any
communication.
4
Flashing
Orange
SYSTEM_INCOMPATIBILITY
The devices have established communication
and determined that they are not
interoperable. This would be the case when
the frame grabber and the camera have
different pixel depth, pixel format and/or
number of lanes.
5
Flashing
Green
LOOKING_FOR_LINK
Hardware is fine, but connection not
established or recently broken.
8
Constant
Green
LINK_GOOD
Link established and data transfer may take
place.
