Dalsa Xtium2-CLHS PX8 - VIC Related Parameters

58 • Xtium2-CLHS PX8 Reference Xtium2-CLHS PX8 User's Manual
CORACQ_PRM_LINE_TRIGGER_DELAY
min = 0 nsec
max = 4294967295 nsec
step = 1 nsec
CORACQ_PRM_CHANNELS_ORDER CORACQ_VAL_CHANNELS_ORDER_NORMAL (0x1)
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MIN 1 Hz
CORACQ_PRM_CAM_LINE_TRIGGER_FREQ_MAX 10000000 Hz
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MIN 1 µs
CORACQ_PRM_CAM_TIME_INTEGRATE_DURATION_MAX 42949672 µs
CORACQ_PRM_CAM_IO_CONTROL (*)
CORACQ_PRM_DATA_VALID_ENABLE TRUE
FALSE
CORACQ_PRM_BAYER_ALIGNMENT Not available
CORACQ_PRM_CAM_CONTROL_DURING_READOUT
CORACQ_VAL_CAM_CONTROL_DURING_READOUT_INVALID (0x0)
CORACQ_VAL_CAM_CONTROL_DURING_READOUT_VALID (0x01)
CORACQ_VAL_CAM_CONTROL_DURING_READOUT_IGNORE (0x2)
CORACQ_PRM_DATA_LANES min = 1 lane, max = 7 lanes, step = 1 lane
CORACQ_PRM_BIT_TRANSFER_RATE 10 Gbps
CORACQ_PRM_CLHS_CONFIGURATION
CORACQ_VAL_CLHS_CONFIGURATION_MANUAL_ACQ_START_STOP
(0x8)
VIC Related Parameters
Parameter Values
CORACQ_PRM_CAMSEL Mono
RGB
CAMSEL_MONO = from 0 to 0
CAMSEL_RGB = from 0 to 0
CORACQ_PRM_CROP_LEFT Mono
RGB
min = 0 pixel
max = 65528 pixel
step = 8 pixel
min = 0 pixel
max = 16376 pixel
step = 8 pixel
CORACQ_PRM_CROP_TOP
min = 0 line
max = 16777215 line
step = 1 line
CORACQ_PRM_CROP_WIDTH Mono
RGB
min =32 pixel
max = 65536 pixel
step =8 pixel
min =32 pixel
max = 16384 pixel
step =8 pixel
* Maximum allowed is 64 kBytes, so maximum in pixels is dependent on
the output pixel depth.
CORACQ_PRM_CROP_HEIGHT
min = 1 line
max = 16777215 line
step = 1 line
CORACQ_PRM_DECIMATE_METHOD CORACQ_VAL_DECIMATE_DISABLE (0x1)
CORACQ_PRM_LUT_ENABLE TRUE
FALSE
CORACQ_PRM_LUT_NUMBER Default = 0
CORACQ_PRM_STROBE_ENABLE
TRUE
FALSE
CORACQ_PRM_STROBE_METHOD CORACQ_VAL_STROBE_METHOD_1 (0x1)
CORACQ_VAL_STROBE_METHOD_3 (0x4)
CORACQ_VAL_STROBE_METHOD_4 (0x8)
CORACQ_VAL_STROBE_METHOD_5 (0x10)
CORACQ_PRM_STROBE_POLARITY CORACQ_VAL_ACTIVE_LOW (0x1)
CORACQ_VAL_ACTIVE_HIGH (0x2)
CORACQ_PRM_STROBE_DURATION
min = 1 µs
max = 42949672 µs
step = 1 µs
