66 • Xtium2-CLHS PX8 Reference Xtium2-CLHS PX8 User's Manual
Sapera Servers and Resources
A Sapera Server is an abstract representation of a physical device like a frame-grabber or camera.
When using the SapAcquisition or SapAcqDevice constructors, the location parameter specifies the
server to use to create the object. Use the Sapera Configuration utility to find the names and
indices of all Sapera servers in your system.
In Sapera LT all frame grabbers are configured using the SapAcquisition class. All CLHS cameras
are GenCP compliant and are configured in Sapera LT using the SapAcqDevice class.
Note: Currently, CLHS cameras do not have their own server, therefore it is available under the
Xtium2_CLHS server. For example, in CamExpert the Xtium2 server displays both the frame grabber
and camera resources.
Servers Resources
Name Type Name Index Description
Xtium2-CLHS_PX8_1
Acquisition
Module
Camera Link HS Mono
Camera Link HS Color
RGB
0
1
CLHS Mono Camera
CLHS RGB Camera
Acquisition
Device
<Device Name>
* Name of Camera
0 CLHS Camera
GIO Module General Outputs #1
General Inputs #1
Bidirectional General
I/Os #1
0
1
2
8 General Outputs
4 General Inputs
8 Bidirectional General I/Os
