Xtium2-CLHS PX8 User's Manual Technical Specifications • 89
Cables & Accessories
The following cables and accessories are available for purchase via third party vendors or Teledyne
DALSA. Contact sales for information.
Camera Link HS Cables Overview and Resources
In general, a CX4 compliant cable assembly is acceptable for use as a CLHS interface cable with
the exception that it must have a thumbscrew type junction shell. This cable assembly is primarily
intended as a point-to-point interface of up to 15 meters.
A manufactured CX4 cable shall use the SFF-8470 multi-sourced connector as specified by the
published standard “SFF-8470 Specification for Shielded High Speed Serial Multilane Copper
Connector (Rev 3.3 April 3, 2006 or later)”.
Cables are also available as CX4 Active optical interconnects allowing much longer distances
between camera and frame grabber.
Visit our web site for additional information on the CLHS interface:
https://www.teledynedalsa.com/en/learn/knowledge-center/clhs/
For additional information on cables and their specifications, visit the following web sites and
search for “Camera Link HS” cables:
Components Express http://www.componentsexpress.com/
Nortech Systems http://www.intercon-1.com/intercon1/
Alysium-Tech https://www.alysium.com/
