Dalsa Xtium2-CLHS PX8 User Manual

62 • Xtium2-CLHS PX8 Reference Xtium2-CLHS PX8 User's Manual
ACQ Related Parameters
Parameter Values
CORACQ_PRM_LABEL Camera Link HS Mono
CORACQ_PRM_EVENT_TYPE CORACQ_VAL_EVENT_TYPE_START_OF_FRAME
CORACQ_VAL_EVENT_TYPE_END_OF_FRAME
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER
CORACQ_VAL_EVENT_TYPE_VERTICAL_SYNC
CORACQ_VAL_EVENT_TYPE_FRAME_LOST
CORACQ_VAL_EVENT_TYPE_DATA_OVERFLOW
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER_IGNORED
CORACQ_VAL_EVENT_TYPE_EXT_LINE_TRIGGER_TOO_SLOW
CORACQ_VAL_EVENT_TYPE_LINK_ERROR
CORACQ_VAL_EVENT_TYPE_SHAFT_ENCODER_REVERSE_COUNT_OVERFLOW
CORACQ_VAL_EVENT_TYPE_LINE_TRIGGER_TOO_FAST
CORACQ_VAL_EVENT_TYPE_EXTERNAL_TRIGGER_END
CORACQ_PRM_EVENT_TYPE_EX
CORACQ_VAL_EVENT_TYPE_LINK_LOCK
CORACQ_VAL_EVENT_TYPE_LINK_UNLOCK
CORACQ_VAL_EVENT_TYPE_CAMERA_MISSED_TRIGGER
CORACQ_VAL_EVENT_TYPE_CAMERA_OVERRUN
CORACQ_PRM_SIGNAL_STATUS
CORACQ_VAL_SIGNAL_HSYNC_PRESENT
CORACQ_VAL_SIGNAL_VSYNC_PRESENT
CORACQ_VAL_SIGNAL_POWER_PRESENT
CORACQ_VAL_SIGNAL_POCL_ACTIVE
CORACQ_VAL_SIGNAL_LINK_LOCK
CORACQ_VAL_SIGNAL_LANE1_LOCK
CORACQ_VAL_SIGNAL_LANE2_LOCK
CORACQ_VAL_SIGNAL_LANE3_LOCK
CORACQ_VAL_SIGNAL_LANE4_LOCK
CORACQ_VAL_SIGNAL_LANE5_LOCK
CORACQ_VAL_SIGNAL_LANE6_LOCK
CORACQ_VAL_SIGNAL_LANE7_LOCK
CORACQ_PRM_FLAT_FIELD_ENABLE TRUE / FALSE
CORACQ_CAP_FLAT_FIELD_OFFSET 8-bit Mono
10-bit Mono
12-bit Mono
14-bit Mono
16-bit Mono
min = 0
max = 255
step = 1
min = 0
max = 4095
step = 1
min = 0
max = 16383
step = 1
min = 0
max = 65535
step = 1
Not Available
CORACQ_CAP_FLAT_FIELD_GAIN
8-bit Mono
10-bit Mono
12-bit Mono
14-bit Mono
16-bit Mono
min = 0
max = 255
step = 1
min = 0
max = 4095
step = 1
min = 0
max = 16383
step = 1
min = 0
max = 65535
step = 1
Not Available
CORACQ_CAP_FLAT_FIELD_GAIN_DIVISO
R
8-bit Mono
10-bit Mono
12-bit Mono
14-bit Mono
16-bit Mono
128
512
2048
8192
Not Available
