Xtium2-CLHS PX8 User's Manual Xtium2-CLHS PX8 Reference • 61
CORACQ_PRM_BOARD_SYNC_OUTPUT1_SOURCE (*)
min = 0
max = 6
step = 1
CORACQ_PRM_BOARD_SYNC_OUTPUT2_SOURCE (*)
min = 0
max = 6
step = 1
CORACQ_PRM_EXT_TRIGGER_SOURCE_STR [0] = Automatic
[1] = External Trigger #1
[2] = External Trigger #2
[3] = Board Sync #1
[4] = Board Sync #2
[5] = Software Trigger
CORACQ_PRM_EXT_LINE_TRIGGER_SOURCE_STR
[0] = Automatic
[1] = Shaft Encoder Phase A
[2] = Shaft Encoder Phase B
[3] = Shaft Encoder Phase A & B
[4] = Board Sync #1
[5] = Board Sync #2
CORACQ_PRM_VERTICAL_TIMEOUT_DELAY Not Available
CORACQ_PRM_POCL_ENABLE TRUE
FALSE
CORACQ_PRM_SHAFT_ENCODER_DIRECTION
CORACQ_VAL_SHAFT_ENCODER_DIRECTION_IGNORE (0x00)
CORACQ_VAL_SHAFT_ENCODER_DIRECTION_FORWARD (0x01)
CORACQ_VAL_SHAFT_ENCODER_DIRECTION_REVERSE (0x02)
CORACQ_PRM_LINE_TRIGGER_AUTO_DELAY
CORACQ_VAL_LINE_TRIGGER_AUTO_DELAY_DISABLE (0x0)
CORACQ_VAL_LINE_TRIGGER_AUTO_DELAY_FREQ_MAX (0x2)
CORACQ_PRM_TIME_STAMP_BASE
CORACQ_VAL_TIME_BASE_US (0x1)
CORACQ_VAL_TIME_BASE_LINE_VALID (0X4)
CORACQ_VAL_TIME_BASE_LINE_TRIGGER (0X8)
CORACQ_VAL_TIME_BASE_SHAFT_ENCODER (0X40)
CORACQ_VAL_TIME_BASE_100NS (0x200)
CORACQ_PRM_BOARD_SYNC_OUTPUT1_SOURCE_STR
[0] = Disabled
[1] = External Frame Trigger
[2] = Reserved
[3] = External Trigger Ignore Region
[4] = Shaft Encoder Before Mult/Drop
[5] = Shaft Encoder After Mult/Drop
[6] = Internal Line Trigger
CORACQ_PRM_BOARD_SYNC_OUTPUT2_SOURCE_STR
[0] = Disabled
[1] = External Frame Trigger
[2] = Reserved
[3] = External Trigger Ignore Region
[4] = Shaft Encoder Before Mult/Drop
[5] = Shaft Encoder After Mult/Drop
[6] = Internal Line Trigger
CORACQ_PRM_SHAFT_ENCODER_ORDER CORACQ_VAL_SHAFT_ENCODER_ORDER_AUTO (0X0)
CORACQ_VAL_SHAFT_ENCODER_ORDER_DROP_MULTIPLY (0X1)
CORACQ_VAL_SHAFT_ENCODER_ORDER_MULTIPLY_DROP (0X2)
* For auto mode, the order is multiply/drop.
CORACQ_PRM_CAM_FRAMES_PER_TRIGGER Not Available
CORACQ_PRM_LINE_INTEGRATE_TIME_BASE CORACQ_VAL_TIME_BASE_NS (0X80)
CORACQ_PRM_EXT_TRIGGER_IGNORE_REGION_DURATION
min = 0 µs
max = 6553 µs
step = 1 µs
